Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction equipment. They make machines like aerial lifts, manlifts and boom lifts. These equipments are designed to facilitate access to difficult to reach areas, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains handholds or platforms or steps which are attached to the unit in order to move employees from every floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The max height of the platform reaches 85 feet, while the maximum width of the model is 8.5 feet. The TB85 has dimensions that measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of seventy feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
